Iniettore tipo 30 (Type 30)
€ 0,00 Iva esclusa
Codice Articolo: CGTYPE30
In stock
Vuoi maggiori informazioni sul nostro prodotto Iniettore tipo 30 (Type 30) puoi inviarci la tua richiesta.
Richiedi info prodotto
Richiedi info prodotto
LPG/CNG Injection Rail, gaseous phase, for calibrated exchangeable nozzles with male thread 1/8”G cyl., available in standard flow version or increased flow “BFC”, coils with incorporated connector compatible with Amp/Delphi superseal 1,5mm, tightness IP 54, body in extruded black anodized Aluminium, standard valve seat Ø 4mm, gas inlet options from either side, one of which bolted, connections for rubber hose internal Ø 10 / 12 mm.
Good performance even with dirty LPG and without fitting a protective filter, simple maintenance and compact overall dimensions. Excellent silent running. Available in 1–4 cylinder models.
Available with temperature sensor and/or with pressure sensor.
Specifiche tecniche
| Material | Aluminum |
|---|---|
| Peso |
4 cyl. » 0,5 kg 3 cyl. » 0,4 kg 2 cyl. » 0,3 kg 1 cyl. » 0,2 kg |
| Omologazione | ECE R67-01, ECE R110, ECE R10-03, ISO 15500 |
Opzioni
|
Ingresso (mm) |
Ø 10 / 12 |
|---|---|
|
Ugelli di uscita calibrata (mm) |
Ø 1,5 to Ø 3,5 step 0,25 Ø 5 Ø 6 |
|
Resistenza elettrica Ω |
1,0 / 2,0 / 3,0 / 6,0 |
