ELETTROVALVOLA TIPO 06 GPL/METANO

CARATTERISTICHE

Valvola on / off di intercettazione senza filtro

Ingresso e uscita maschio filettato su richiesta

Montare la valvola e connettersi ad alimentare tubo di alimentazione o tubo

SPECIFICHE TECNICHE

Material              Brass

Available applications    LPG, CNG, petrol, diesel

Max. working pressure                0,15 MPa (marine applications) 0,7 MPa (bpetrol and gasoline) 3 MPa ( LPG, CNG)

Working temperature   -40°C +120°C

Approval             ECE R67-01 ECE R110 UL standard 429 ECE R10-03

Flow rate with air [nl/h]

varying pressure at ambient temperature          16500 @ 1 bar – 26500 @ 2 bar

Fixing

Coil armature with holes             Ø 5,5 mm – Ø 6,5 mm

Coil type Small

12 V – 11 W        Lucar Plugs connection

Coil type Small

12 V – 8 W          Lucar plugs and ground connector

Coil type Big

24 V – 11 W        AMP SUPERSEAL 1.5 connection

Coil type Big

24 V – 8 W          Connection wires L=140mm

Coil type Small

12 V – 8 W + diodo          SICMA 2

OPZIONI

Ingresso              (A) ¼”-18 NPT F

Uscita, Connessione      (B) ¼”-18 NPT F
